# ADP107 CEC Module

Consumer Electronics Control (CEC) Product Manual

<figure><img src="https://3062424488-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FlLHqs7kbNoKOFTwGOfH6%2Fuploads%2FkrJ8orMOx15e536a3gEN%2Fimage.png?alt=media&amp;token=79c1e11b-1934-4368-bb0a-ffd7c29ade31" alt=""><figcaption></figcaption></figure>

<figure><img src="https://3062424488-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FlLHqs7kbNoKOFTwGOfH6%2Fuploads%2FNyoYHzYH6i11HnFh1b5a%2Fimage.png?alt=media&amp;token=0ae616cf-e594-473f-803b-a9ee666d04a6" alt=""><figcaption></figcaption></figure>

<figure><img src="https://3062424488-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FlLHqs7kbNoKOFTwGOfH6%2Fuploads%2FsBGkRuPPyuu8YUVV8YXs%2Fimage.png?alt=media&amp;token=887e3792-1823-47af-8cd1-962483ee4179" alt=""><figcaption></figcaption></figure>

<figure><img src="https://3062424488-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FlLHqs7kbNoKOFTwGOfH6%2Fuploads%2FERuaudAgWCck3oq4TYdj%2Fimage.png?alt=media&amp;token=1f619db0-125f-4b25-9574-b66fe90144bb" alt=""><figcaption></figcaption></figure>
